Name: low cost high quality low differential pressure sensor,Protection IP65
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXSENSORS-PS540
Price: 61.00 USD
Availability: InStock

Rumah > Produk > Fluid Level Meter >

low cost high quality low differential pressure sensor,Protection IP65

Tempat asal:

Cina

Nama merek:

KACISE

Sertifikasi:

Model Number:

GXSENSORS-PS540

Hubungi Kami

Minta Kutipan

low cost high quality low differential pressure sensor,Protection IP65

Rincian produk

Usage:

PRESSURE SENSOR

Theory:

Resistance Sensor

Output:

Analog SENSOR

Certificate::

Warranty:

12 months exchange

Type:

low differential pressure sensor

Port:

Shanghai or other

Medium temperature:

-10~100°C

Protection:

IP65

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 PCS

Harga

$55.00 - $68.00/pieces

Kemasan rincian

Setiap unit memiliki kotak individual dan semua kotak dikemas dalam paket standar atau permintaan pe

Delivery Time

5-8 work days

Payment Terms

T/T, Western Union, MoneyGram

Menyediakan kemampuan

1000 Potongan/potongan per Minggu bisa dinegosiasikan

Produk terkait

Video

KDI Series Display Controller Mendukung Komunikasi Multi - Machine

Dapatkan Harga Terbaik

Video

KDI Series Display Controller dengan Open Internal Parameter Setting Interface Keakuratan Tinggi dan Resolusi 0,1

Dapatkan Harga Terbaik

Video

Kontroler Tampilan Pengukuran Seri KDI yang akurat dengan Multiple Index Input Switching dan Kompensasi Suhu

Dapatkan Harga Terbaik

Video

KDI Series Light Column Display Controller Dengan Pengukuran Digital Dan Analog

Dapatkan Harga Terbaik

Hubungi Kami

86--17719566736

Hubungi Sekarang

Deskripsi Produk

low cost high quality low differential pressure sensor

Feature

High sensitivity

High accuracy and high stability

Mini outline, easy to install

Application

Boiler

Dust precipitator

Air duct pressure

Differential and negativepressure

Instruction

GXPS540 series low differential pressure sensor Wind Pressure & Differential Pressure Transmitter adopts high-precision, high stability diaphragm and is assembled by stress isolation technics. By strict precision temperature compensation and signal amplification, transfer micro differential pressure, air pressure, flow and other parameters to reliable 4~20mA or 1~5V signal output.

Parameter of 2024 low cost high quality low differential pressure sensor

Measuring range:	0-100Pa~100Kpa; -50KPa~-50Pa-50Pa~50Kpa
Protection:	IP65
Medium Measurement:	Non-corrosive dry gas; weak corrosive and damp gas
Output signal:	4~20mA, 1~5V, 0~5V Optional
Operating voltage:	24VDC
Accuracy:	±0.2% F.S., ±0.5% F.S., ±1% F.S. Optional
Adjustment	Zero and range are adjustable externally
Medium temperature:	-10~100°C
Ambient temperature :	-20~80°C
Electric Interface:	outlet cable
Shell material:	Aluminum alloy

Dimension

low cost high quality low differential pressure sensor,Protection IP65 0

Ordering information

GXPS540						Product Serial
	X (Pa or KPa)					Pressure Range
		0.3				±0.3%FS Accuracy
		0.5				±0.5%FS Accuracy
		1.0				±1%FS Accuracy
			4mA			4~20mA Output
			V0			0~5VDC Output
			V1			1~5VDC Output
			RSV			reserved
				F8		Φ8 tower-type interface
				RSV		reserved
					CX	X meters Cable
					RSV	reserved
GXPS540	1KPa	0.3	4mA	F6	C2	Example
