Name: 4 - 20ma Liquid Water Level Sensor / Fuel Level Sensor Waterproof
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: GXPS400
Price: 244.00 USD
Availability: InStock

Rumah > Produk > Fluid Level Meter >

4 - 20ma Liquid Water Level Sensor / Fuel Level Sensor Waterproof

20ma Liquid Level Sensor

Fuel Level Sensor Waterproof

Place of Origin:

CHINA

Nama merek:

KACISE

Sertifikasi:

Model Number:

GXPS400

Hubungi Kami

Minta Kutipan

4 - 20ma Liquid Water Level Sensor / Fuel Level Sensor Waterproof

Rincian produk

Usage:

Level Sensor

Theory:

Resistance Sensor

Output:

Analog SENSOR

Pressure range:

0~1...500mH2O

Port:

Shanghai or other

Menyoroti:

20ma Liquid Level Sensor

Fuel Level Sensor Waterproof

Syarat Pembayaran & Pengiriman

Minimum Order Quantity

1PCS

Harga

$99.00 - $390.00/pieces

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Supply Ability

1000 Piece/Pieces per Week negotiable

Produk terkait

Video

KDI Series Display Controller Mendukung Komunikasi Multi - Machine

Dapatkan Harga Terbaik

Video

KDI Series Display Controller dengan Open Internal Parameter Setting Interface Keakuratan Tinggi dan Resolusi 0,1

Dapatkan Harga Terbaik

Video

Kontroler Tampilan Pengukuran Seri KDI yang akurat dengan Multiple Index Input Switching dan Kompensasi Suhu

Dapatkan Harga Terbaik

Video

KDI Series Light Column Display Controller Dengan Pengukuran Digital Dan Analog

Dapatkan Harga Terbaik

Hubungi Kami

86--17719566736

Hubungi Sekarang

Deskripsi Produk

GXPS400 serial 4-20ma liquid water level sensor

1. Specification of GXPS400 serial 4-20ma liquid water level sensor :

Spec.	Numerical value			Remark
Pressure range	0~1……500mH2O			1mH2O≈9.81kPa
Overload pressure	1.5times Rated pressure
fracture pressure	3 times rated pressure
Accuracy	±0.25%F.S, ±0.5%F.S, ±1.0%F.S
Accuracy	±0.25%F.S, ±0.5%F.S, ±1.0%F.S
Stability	Typical value: 0.1%F.S Max.: 0.2% F.S/year
Operating Temperature	-40°C~85°C or -40 °C ~125 °C
compensation temperature	-10°C~70°C
medium compatibility	All Caustic Medium Compatible with 1Cr18Ni9Ti and 316L
electrical properties	2 line	3 line
Output signal	4~20mA	0~5V	0~10V
Power supplies	10~30Vdc	80~30Vdc/ac	11~30Vdc/ac	Vdc/ac
load resistance	(U-10)/0.02( )	more than 100k
insulation	more than 100M @50V
Electrical Connections	waterproof fixed cable + Two rectangle circle+Sealing Rings+seal gum+ Pure glue protection grade : IP68
pressure interface	G1/4,input type
response time	10ms
Electric strength	500Vac@1 second
Graduate Certificate Programs	certificate of explosion-proof, CE
electromagnetic compatibility	electromagnetic radiation EN50081-1/-2, electromagnetic susceptibilty: EN50082-2
lightning protection	air conduction resistance 8000V,case, cable conduction
