Name: NPT Thread Installation KLD801 Water Level Radar Sensor For Non Corrosive Liquid
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KLD801
Price: 1,000.00 USD
Availability: InStock

Rumah > Produk > Fluid Level Meter >

NPT Thread Installation KLD801 Water Level Radar Sensor For Non Corrosive Liquid

NPT Thread Water Level Radar Sensor

Non Corrosive Liquid Radar Sensor

0.05m Fluid Level Meter

Place of Origin:

CHINA

Nama merek:

KACISE

Sertifikasi:

Model Number:

KLD801

Hubungi Kami

Minta Kutipan

NPT Thread Installation KLD801 Water Level Radar Sensor For Non Corrosive Liquid

Rincian produk

Medium:

liquid, non-corrosive

Measuring range:

0.05m～10/20/30/60/100m

Process connection:

G1½A / 1½NPT thread

Process temperature:

-40～80℃

Process pressure:

-0.1～0.3 MPa

Antenna size:

32mm lens antenna

Antenna material:

PTFE

Accuracy:

±1mm

Protection class:

IP67

Center frequency:

80GHz

Launch angle:

3°

Power supply:

DC24V/DC12~24V

Casing:

aluminum/plastic/stainless steel

Signal output:

4...20mA/HART protocol/RS485 Modbus

Menyoroti:

NPT Thread Water Level Radar Sensor

Non Corrosive Liquid Radar Sensor

0.05m Fluid Level Meter

Syarat Pembayaran & Pengiriman

Minimum Order Quantity

1PCS

Harga

dapat dinegosiasikan

Packaging Details

each unit has individual box and all boxes are packed in standard packages or customers requests available

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

1000 Piece/Pieces per Week negotiable

Produk terkait

Video

KDI Series Display Controller Mendukung Komunikasi Multi - Machine

Dapatkan Harga Terbaik

Video

KDI Series Display Controller dengan Open Internal Parameter Setting Interface Keakuratan Tinggi dan Resolusi 0,1

Dapatkan Harga Terbaik

Video

Kontroler Tampilan Pengukuran Seri KDI yang akurat dengan Multiple Index Input Switching dan Kompensasi Suhu

Dapatkan Harga Terbaik

Video

KDI Series Light Column Display Controller Dengan Pengukuran Digital Dan Analog

Dapatkan Harga Terbaik

Hubungi Kami

86--17719566736

Hubungi Sekarang

Deskripsi Produk

KLD801 80G FM Radar Level Sensor

Introduction

KLD801 series 80G FM radar level sensor supports four-wire and two-wire applications. Multiple models, the maximum range of the product can reach 100m, and the blind zone can reach 5cm.
Due to its higher operating frequency and shorter wavelength, it is suitable for non-corrosive liquid applications, and the working method of transmitting and receiving electromagnetic waves through the lens has unique advantages in normal temperature and pressure environments. The instrument adopts screw fixing method, which makes the installation convenient and simple.

Feature

G1½A / 1½NPT thread installation
Suitable for non-corrosive liquid measurement
80GHz high frequency radar,narrow beam angle, the energy is more concentrated, the directionality is better, and the echo intensity is higher.
The antenna is small in size and easy to install;
Non-contact radar, no wear, no pollution.

KLD801

NPT Thread Installation KLD801 Water Level Radar Sensor For Non Corrosive Liquid 0

Medium: liquid, non-corrosive

Measuring range: 0.05m～10/20/30/60/100m

Process connection: G1½A / 1½NPT thread

Process temperature: -40～80℃

Process pressure: -0.1～0.3 MPa

Antenna size: 32mm lens antenna

Antenna material: PTFE

Accuracy: ±1mm

Protection class: IP67

Center frequency: 80GHz

Launch angle: 3°

Power supply: Two-wire /DC24V

Four-wire system/DC12~24V

Four-wire system/AC220V

Casing: aluminum/plastic/stainless steel

Signal output: two-wire /4...20mA/HART protocol

Four-wire system: 4...20mA/ RS485 Modbus

Standard thread dimensions table chart

NPT Thread Installation KLD801 Water Level Radar Sensor For Non Corrosive Liquid 1

Product Dimension

Unit in mm:

Installation Method

Thread installation
