Name: Fast Response High Accuracy KSCCP21D Capacitive Ceramic Pressure Element CCP Series
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KSCCP21D
Price: 5.60 USD
Availability: InStock

Rumah > Produk > Sensor Transduser Ultrasonik >

Fast Response High Accuracy KSCCP21D Capacitive Ceramic Pressure Element CCP Series

Capacitive Ceramic Pressure Element

CCP Pressure Element

Place of Origin:

China

Nama merek:

Kacise

Model Number:

KSCCP21D

Hubungi Kami

Minta Kutipan

Fast Response High Accuracy KSCCP21D Capacitive Ceramic Pressure Element CCP Series

Rincian produk

Dimensions of Chip:

φ21

Pressure Range:

0.1～10Mpa

Total error:

0.1...0.2FS%

Isolation:

>4KV

Temperature drift:

±0.01 %FS/℃

Working temperature:

-40～125℃

Menyoroti:

Capacitive Ceramic Pressure Element

CCP Pressure Element

Syarat Pembayaran & Pengiriman

Minimum Order Quantity

Harga

5.6~5.8USD/pc

Packaging Details

carton

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100+

Produk terkait

Sensor jarak bawah air KUS-W80 200kHz Frekuensi transduser dan arus bebas beban rendah untuk pengukuran jarak bawah air

Dapatkan Harga Terbaik

KUS-W50 Sensor Jarak Bawah Air Perlindungan Polaritas Balik Dan Area Buta 0,6m Untuk Pemantauan Bawah Air Tanpa Kerumitan

Dapatkan Harga Terbaik

KWD200 Sensor Komunikasi Bawah Air Ultrasonik

Dapatkan Harga Terbaik

KWD400 360 derajat pemindaian sonar presisi tinggi Konsumsi daya ≤ 12W

Dapatkan Harga Terbaik

Hubungi Kami

86--17719566736

Hubungi Sekarang

Deskripsi Produk

Capacitive Ceramic Pressure Element– CCP Series

Operating Temp. : -40~150℃

FEATURES

● Ceramic capacitor type
● Measurement without intermediary liquid
● Fast response and high accuracy
● High reliability
● AEC-Q200D verified

APPLICATIONS

● For automotive oil pressure measurement, refrigerant pressure measurement of air conditioner, etc.

Fast Response High Accuracy KSCCP21D Capacitive Ceramic Pressure Element CCP Series 0

SHAPE AND DIMENSIONS

Fast Response High Accuracy KSCCP21D Capacitive Ceramic Pressure Element CCP Series 1

SPECIFICATIONS

Part No.	Pressure range(Mpa)	Pressure range	Over pressure/times of norminal value	Burst pressure/times of norminal value	Capacitor value without load	Thickness
KSCCP21DX100-E1	0.1	14.5	3	5	15-25	4.06±0.1
KSCCP21DX200-E1	0.2	29	3	5	15-23	4.06±0.1
KSCCP21DX500-E1	0.5	72.5	3	5	17-32	4.22±0.1
KSCCP21DX1000-E1	1	145	3	5	15-22	4.34±0.1
KSCCP21DX2000-E1	2	290	3	5	15-24	4.42±0.1
KSCCP21DX4000-E1	4	580	3	5	15-24	4.57±0.1
KSCCP21DX5000-E1	5	725	3	5	15-24	4.70±0.1
KSCCP21DX8800-E1	8.8	1276	3	5	20-32	6.53±0.1

*X: G: Sealed Gage, A: Absolute

Temperature character

Fast Response High Accuracy KSCCP21D Capacitive Ceramic Pressure Element CCP Series 2

Techinical parameters

Pressure range	0.1～10Mpa
Response time	<1mS
Total error(Nu-linertiy+hysteresis+repeatibility)	0.1...0.2FS%
Isolation	>4KV
Isolation resistor@100VDC	>500M
Temperature drift	±0.01 %FS/℃
Long term stability	<0.1% FSO/年
Working temperature	-40～125℃

Fast Response High Accuracy KSCCP21D Capacitive Ceramic Pressure Element CCP Series 3
