KUS630 auto power return industrial ultrasonic parking sensors 15m range and 4~20mA output

Place of Origin:

China

Nama merek:

Kacise

Model Number:

KUS630C

Hubungi Kami

Minta Kutipan

Rincian produk

Range:

15m

Output:

4~20mA/NPN/PNP/RS485/0-3V，0-5V

Power supply:

3.3-24 V

Working current:

≤45mA

Temperature compensation:

Yes

Working temperature:

-25…70℃(248...343K)

Protection class:

IP68

Shell material:

PVDF

Measurement accuracy:

≤1 %

Syarat Pembayaran & Pengiriman

Minimum Order Quantity

Harga

dapat dinegosiasikan

Packaging Details

15*15*10cm，1.2kg

Delivery Time

5-8 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100+

Produk terkait

Sensor jarak bawah air KUS-W80 200kHz Frekuensi transduser dan arus bebas beban rendah untuk pengukuran jarak bawah air

Dapatkan Harga Terbaik

KUS-W50 Sensor Jarak Bawah Air Perlindungan Polaritas Balik Dan Area Buta 0,6m Untuk Pemantauan Bawah Air Tanpa Kerumitan

Dapatkan Harga Terbaik

KWD200 Sensor Komunikasi Bawah Air Ultrasonik

Dapatkan Harga Terbaik

KWD400 360 derajat pemindaian sonar presisi tinggi Konsumsi daya ≤ 12W

Dapatkan Harga Terbaik

Hubungi Kami

86--17719566736

Hubungi Sekarang

Deskripsi Produk

KUS630 Series Ultrasonic Level Meter

1.Features

The parking space monitoring system based on the Internet of Things automatically guides the vehicle to enter the empty parking space quickly, reduces the cost of management personnel, eliminates the trouble of finding a parking space, and saves time.
Low power consumption technology;
High dustproof level;
Corrosion resistance;
High resolution;
Can remove clutter and detect the distance information of the target well.

2. Dimensions
Unit in the diagram is mm.

KUS630 auto power return industrial ultrasonic parking sensors 15m range and 4~20mA output 0

3.Electrical connections and signal definitions
KUS630 auto power return industrial ultrasonic parking sensors 15m range and 4~20mA output 1

Line order	Colour	Definition
1	Red	Power is positive
2	Black	power return ground
3	Yellow	Analog output, voltage output, current output switch output
4	Blue	RS485 A+ or uart TXD
5	Green	RS485 B- or uart RXD

Cable color	Line order	Describe	Remark
red	1	powered by	3.3V-30V wide voltage input
black	2	GND
yellow	3	Switch output	Switch terminal, load capacity 1A 60V, supports up to two switch outputs with independent logic, the two terminals are the two contacts of the switch, do not distinguish between positive and negative poles, and can be connected at will.
White	4	Switch output
brown	4	RS485A+
green	5	RS485B-

4.Parameter description

Model:KUS630
Measuring range	0.8m... 15m
Blind spot	0 ... 0.6m(Unstable working area is within 0.6m, it is not recommended to work in this range); the minimum blind area version of 0.3m can be achieved, which needs to be customized.
Supply voltage	3.3 ... 24 V DC , ripple 10 %SS

Working current	≤ 45 mA (fastest measurement speed) Low-power version, sleep power consumption is less than 0.3mA, sending power consumption is 20mA (less than 2ms), and receiving power consumption is not more than 8mA (less than 150ms)
Output signal	1:Programmable analog output 0-10V. 2:RS485 output. 3:Uart serial output 4:4-20mA output 5:Switch output
Measurement accuracy	≤1 %
Temperature compensation	yes

working conditions

Working temperature	-25…70℃(248...343K)
Storage temperature	-40…85℃(233...358K)

other instructions

Electrical connection	5-core cable (analog output), 6-core cable (switch output)；
Protection class	IP68
Shell material	PVDF

5. Ordering Information

KUS	Model	Output	Range	Describe
	630C	Support customization
	Custommade
		0-10V	Analog 0-10V output
		0-5V	Analog 0-5V output
		0-3V	Analog 0-3V output
		4-20mA	Analog 4-20mA output
		SW	Switch output
		Uart	Uart serial output MODBUS RTU protocol
		RS485	RS485 output MODBUS RTU protocol
			XXX mm	XXX mmmeans the maximum measurement distance (default15000mm)
KUS	550	RS485	10000mm

6.Application data

KUS630 auto power return industrial ultrasonic parking sensors 15m range and 4~20mA output 2
