Deskripsi Produk

KUM-E Digital Intergral Explosion-Proof Ultrasonic Level Meter Non-Contact Level Sensor

KUM-E ultrasonic explosion-proof level meter is a non-contact and cost-effective level meter with high reliability, high accuracy and easy installation. It does not have to contact the medium and can meet the measuring requirements of most applications.

1. Technical Features:

Non-contact, can be used in various applications;
High accuracy: 0.5%, 1%
Various types of probes are available to meet the requirements of various applications;
explosion-proof, can be used in harzard environments.

2. Structure:

Ultrasonic Non Contact Fluid Level Meter KUM-E Digital Integral Explosion Proof 0

3. Technical Specifications:

Specs	Value
Pressure Voltage	5m, 10m, 15m, 20m, 30m, 40m, 50m, 60m
Accuracy	0.5%, 1.0%
Display	LCD
Ambient Temperature	Display instrument-20～+60℃ transducer-20～+80℃
Medium	liquid and solid
Analog Output	4-20mA
Digital Output	RS485, RS232 (both are optional)
Power Supply	24Vdc
Protection Grade	Display instrument IP65,transducer IP68
Probe Type	PVDF, aluminum alloy, ABS, stainless steel 316L, teflon, titanium alloy

4. Model Selection:

KUM-A
	Measurement Range
	A	5m
	B	10m
	C	15m
	D	20m
	E	30m
	F	40m
	G	50m
	H	60m
		Output Signal
		A	4-20mA
			Accuracy
			0.5	0.5%
			1.0	1%
				Power Supply
				A	24Vdc
				B	11~30Vdc
					Probe Type
					A	PVDF
					B	Aluminum alloy
					C	ABS
					D	Stainless steel 316L
					E	Teflon
					F	Titanium alloy

5. Applications and Installations:

Distance measurement
Depth measurement
