Name: Dwyer Magnehelica Mechanical Micro Differential Pressure Gauge With 0.5kg Load Capacity
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: 2000-60 tahun
Price: 152.00 USD
Availability: InStock

Rumah > Produk > Sensor tekanan presisi >

Dwyer Magnehelica Mechanical Micro Differential Pressure Gauge With 0.5kg Load Capacity

Dwyer Mechanical Micro Differential Pressure Gauge

Micro Differential Pressure Gauge

Nama merek:

Dwyer

Sertifikasi:

Nomor model:

2000-60 tahun

Hubungi Kami

Minta Kutipan

Dwyer Magnehelica Mechanical Micro Differential Pressure Gauge With 0.5kg Load Capacity

Rincian produk

Warranty:

1 Year

Model Number:

2000 Series

Type:

Differential

Connection:

1/4NPT

Weight:

0.5kg

Customized Support:

OEM, ODM

Menyoroti:

Dwyer Mechanical Micro Differential Pressure Gauge

Micro Differential Pressure Gauge

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 PCS

Kemasan rincian

Setiap unit memiliki kotak individual dan semua kotak dikemas dalam paket standar atau permintaan pe

Waktu pengiriman

5-8 hari kerja

Syarat-syarat pembayaran

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Menyediakan kemampuan

1000 Potongan/potongan per Minggu bisa dinegosiasikan

Produk terkait

KMC2000MICRO DIFFERENSIAL PRESSURE GAUGE

Dapatkan Harga Terbaik

Dwyer Magnesense MS-111 Transmitter Tekanan Diferensial Mikro

Dapatkan Harga Terbaik

Pengukur Tekanan KMC-Y250BF 0-60mpa untuk Media Cairan Gas Air Minyak

Dapatkan Harga Terbaik

3000MR 3000MRS Pengukur Tekanan Kombinasi Dengan Titik Setel Tinggi dan Rendah

Dapatkan Harga Terbaik

Hubungi Kami

86--17719566736

Hubungi Sekarang

Deskripsi Produk

Dwyer Magnehelica Mechanical Micro Differential Pressure Gauge With 0.5kg Load Capacity

Attribute	Value
Warranty	1 Year
Model Number	2000 Series
Type	Differential
Connection	1/4NPT
Weight	0.5kg
Customized Support	OEM, ODM

Product Introduction

Dwyer Magnehelica mechanical differential pressure gauge delivers high-precision measurement within ±2% of full scale, featuring 81 selectable ranges to precisely meet diverse application needs. Utilizing simple, non-wearing Magnehelica moving components, this gauge rapidly indicates low pressures of air or non-corrosive gases—including positive pressure, negative pressure (vacuum), or differential pressure.

Engineered to resist shock, vibration, and overpressure, it eliminates issues like manometer liquid evaporation, freezing, or poisoning, while offering a cost-effective solution. Widely applied in measuring fan pressure, blower resistance, filter pressure drop, wind speed, furnace draft, orifice plate pressure loss, foaming system liquid level, fluid amplifier pressure, and hydraulic system pressure. It also detects gas-to-air ratio controls, automatic valves, and monitors blood/respiratory pressure in medical care equipment.

Key Features

High Accuracy: ±2%~4% of full scale at 21°C (70°F), ensuring reliable measurements.
Versatile Ranges: 81 range options with metric/imperial units for flexible applications.
Non-Wearing Design: Magnetic transmission eliminates friction, wear, and hysteresis.
Robust Construction: Shock, vibration, and overpressure resistant; no liquid-related failures.
Easy Installation: Surface or flush mounting; compatible with Model A-610 pipe mount.
Calibration Flexibility: Adjustable for horizontal/vertical use (re-zero for optimal accuracy).
