KFDO601 dissolved oxygen sensor with anti-interference and RS485 interface with precision ±2%

Dissolved Oxygen Sensor RS485 Interface

Dissolved Oxygen Sensor Anti Interference

Place of Origin:

CHINA

Nama merek:

kacise

Sertifikasi:

Model Number:

KFDO601

Hubungi Kami

Minta Kutipan

KFDO601 dissolved oxygen sensor with anti-interference and RS485 interface with precision ±2%

Rincian produk

Measuring principle:

Fluorescence method

Range ability:

0~20mg/L (0 ≤ 200% saturation)

Resolution ratio:

0.01mg/L，0.1℃

Precision:

±2%F.S.，±0.5℃

Temperature compensation:

Automatic temperature compensation（Pt1000）

Output mode:

RS-485 bus, Modbus-RTU protocol

Menyoroti:

Dissolved Oxygen Sensor RS485 Interface

Dissolved Oxygen Sensor Anti Interference

Syarat Pembayaran & Pengiriman

Minimum Order Quantity

0-100

Harga

$0-$2000

Packaging Details

Common package or custom package

Delivery Time

3-10days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

100

Produk terkait

KCW102 Perangkat pengolahan air gelombang elektromagnetik frekuensi rendah

Dapatkan Harga Terbaik

KCW101 Frekuensi - Peralatan pengolahan air gelombang elektromagnetik yang dimodulasi

Dapatkan Harga Terbaik

KHM100 Monitor Kualitas Air Logam Berat Otomatis Online

Dapatkan Harga Terbaik

KCW104 Frekuensi efisiensi tinggi - Perangkat menyapu

Dapatkan Harga Terbaik

Hubungi Kami

86--17719566736

Hubungi Sekarang

Deskripsi Produk

KFDO601 Online Fluorescence Dissolved Oxygen No Electrolyte Is Required And Will Not Be Polarized No Oxygen Consumption

1.Dissolved oxygen measurement applications

Food and Beverages
The pharmaceutical
Energy and electricity
education
The government
water
Waste water management

2.the Difference of Polarographic probe and optical probe

	Polarographic probe	optical probe
maintence	Replace the electrolyte approximately every 2 months and polish the cathode as needed to clean the probe	Clean probe, cover and optical window as needed
storage	Stored in a wet calibration sleeve;For long-term storage, remove the film cover and store in a dry place	Store in a wet calibration sleeve
film	Replace approximately every 2 months as needed	no
solution	Replace approximately every 2 months as needed	no
Need to preheat	(30-60 minutes) if only connected to the meter
stir	need	unnecessary
disturb	Ozone, sulfides, sulfur dioxide, nitrous oxide and carbon monoxide

3.Feature

No electrolyte is required and will not be polarized.
No oxygen consumption, not affected by flow rate.
Built-in temperature sensor, automatic temperature compensation.
Free from interference by chemicals such as sulfides
Small drift, rapid reaction, more accurate measurement.
Long service cycle, lower cost of use.
Simple replacement of fluorescent cap.
Rs-485 interface, Modbus/RTU protocol.
Low power consumption,anti-interference.

4.Technical Specifications

Model	KFDO601
Measuring principle	Fluorescence method
Range ability	0~20mg/L (0 ≤ 200% saturation)
Resolution ratio	0.01mg/L,0.1℃
Precision	±2%F.S.,±0.5℃
Temperature compensation	Automatic temperature compensation(Pt1000)
Output mode	RS-485 bus, Modbus-RTU protocol
Working conditions	0～45℃,<0.2MPa
Storage temperature	-5～65℃
Installation mode	Immersion mounting
Cable length	5 meters, other lengths customizable
Power dissipation	＜0.3W@12V
Source	12～24VDC ±10%
levels of protection	IP68
Calibration	Two-point calibration
Fluorescent cap life	Guaranteed use for one year (under normal use)
Sensor shell material	POM and 316L stainless steel

5.Dimensional Drawing

Name: KFDO601 dissolved oxygen sensor with anti-interference and RS485 interface with precision ±2%
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KFDO601
Price: 2000 USD
Availability: InStock

KFDO601 dissolved oxygen sensor with anti-interference and RS485 interface with precision ±2% 0

Note:The sensor connector is m16-5 core waterproof connector male.

6.Installation

KFDO601 dissolved oxygen sensor with anti-interference and RS485 interface with precision ±2% 1

The sensor shall be installed fixedly below the liquid level. The installation and use shall avoid collision or scraping against the surface of the fluorescent film head. The fluorescent film head part shall avoid being attached by the bottom sediment.Remove the rubber cover when use.

Contact Us

Website www.kacise.com
Phone +86-17719566736
Email sales@kacise.com
Location Tangyan South Road, High-tech Zone, Xi'an City, Shaanxi Province, China
KFDO601 dissolved oxygen sensor with anti-interference and RS485 interface with precision ±2% 2
