Name: Precision Fluid Level Meter Ultrasonic Level Transmitter 200mm - 3000mm Detection Range
Brand: Xi'an Kacise Optronics Co.,Ltd.
SKU: KUS550
Price: 1,000.00 USD
Availability: InStock

Rumah > Produk > Fluid Level Meter >

Precision Fluid Level Meter Ultrasonic Level Transmitter 200mm - 3000mm Detection Range

ultrasonic level transmitter

ultrasonic liquid level sensor

Tempat asal:

Cina

Nama merek:

KACISE

Sertifikasi:

Model Number:

KUS550

Hubungi Kami

Minta Kutipan

Precision Fluid Level Meter Ultrasonic Level Transmitter 200mm - 3000mm Detection Range

Rincian produk

Detection Range:

200mm-3000mm

Response Time:

<50ms

Beam Angle:

7° ± 2

IP Grade:

IP65

Operating Voltage:

24VDC

Output:

Digital Output RS485 Anaolue Output 0-5V Switch Output 0V /5V

Menyoroti:

ultrasonic level transmitter

ultrasonic liquid level sensor

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1 PCS

Harga

dapat dinegosiasikan

Kemasan rincian

Setiap unit memiliki kotak individual dan semua kotak dikemas dalam paket standar atau permintaan pe

Waktu pengiriman

5-8 hari kerja

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Menyediakan kemampuan

1000 Potongan/potongan per Minggu bisa dinegosiasikan

Produk terkait

Video

86--17719566736

Hubungi Sekarang

Deskripsi Produk

Easy install Low power NBiot wireless PVDF Material ultrasonic level transmitter

1.Product Description

This sensor provides very short to long-range detection and ranging, in a compact, robust PVC housing,
designed to meet IP65.

2. Product features:

Designed for outdoor or indoor environments
High sensitivity
Free run operation can continually measure and output ranger information
Sensor beam angle is 7 degrees

3. Parameter

General Parameters		Mechanical Parameter
Detection Range	200mm-3000mm	Connection	5 Pin Cable
Transducer Frequency	125KHz	Weight	100g
Repeatability Precision	≤1%	IP Grade	IP65
Response Time	<50ms
Beam Angle	7° ± 2
Temp. Compensation	Inside/outside/fix temp.
Electrical Parameters
Operating Voltage	24VDC
Limit Working Voltage	13VDC-30VDC
Power Consumption	≤30mA
Circuit Protection	short-circuit protection, overload protection
Output	Digital Output	RS485
	Anaolue Output	0-5V
	Switch Output	0V /5V
Ambient Environment
Operating Ambient Temp.	0-70°C (-40-85°C, -55-125°C, etc, customizable )
Storage Temperature	-40-125°C

4.Dimensions

Precision Fluid Level Meter Ultrasonic Level Transmitter 200mm - 3000mm Detection Range 0

5.Wiring

Precision Fluid Level Meter Ultrasonic Level Transmitter 200mm - 3000mm Detection Range 1

6.Application

Tank level measurement
Bin level measurement
Proximity zone detection
People detection
Robot ranging sensor
Autonomous navigation
Multi-sensors navigation
Distance measuring
Long range object detection
Industrial automation
